Model 00

The Model 00 is very similar to the Mark 13 I mentioned over at http://blog.fsck.com/2013/12/better-and-better-keyboards.html, though it (finally) uses a PCB I designed and had Seeed Studio make me 10 copies of (for $200, including FedEx Next Day shipping from China!) and has a shell made from stained, polyurothane-coated birch plywood rather than acrylic sheets. It's pretty close to a "final" layout for the keyboard we're hoping to Kickstarter.

So far, we've built out four of our 10 PCBs. Two of them are for us. The other two are being sent to unsuspecting beta testers tomorrow. (They won't get there in time for Christmas, but what can you do?) We're not 100% sure what we're doing with the other six, but if we sell any of them, we'll tell the keyboard.io mailing list.





You can find more photos of the Model 00 on Flickr.

Better and better keyboards.

It's been a while since I've written about my keyboard-building adventures....apparently, I haven't blogged about keyboards since April of this year. I've been too busy designing keyboards.

The first thing I should get out of the way is that you're going to be able to buy one. We're working hard to finalize a design and find manufacturing partners. If you want to know when we're ready to take your money, head on over to http://keyboard.io and sign up for our announcement list.

When I last wrote about keyboards here, I'd just completed my first fully homebrew design - the Mark 2 keyboard. From my phrasing, it was pretty clear that I intended to tell you about the Mark 3 that I'd already built.

Mark 3 Keyboard

The Mark 3 was an attempt to build the most compact, yet reasonably ergonomic keyboard I could. It was also the first time I got to drive the lasercutter myself. As such, the folks at Danger!Awesome had me use plywood rather than acrylic.

The keys were arranged in what's known as a 'symmetric stagger' It was quite compact. And I didn't like it at all. Among other things, the thumb keys just weren't as comfortable as I wanted.

Mark 4 Keyboard

The Mark 4 was the first thing that started to feel right. It was also my first foray into TRON-style thumb keys. I loved them. And hated them. I got the angles and positioning wrong. And my brilliant idea of having two rows per-thumb was a total bust. They just made it harder to hit either row. But it looked cool. Man did it look cool.

Mark 5 Keyboard

The Mark 5, I finished just in time for Valentine's Day. A friend remarked that it looked kind of like a heart. So I made it look a lot like a heart. It was actually pretty good, but had a couple fatal flaws.

I was late for my lasercutting appointment when I decided to place the heart...and I misaligned it. I ended up having to dremel notches into a couple of the number-row keys in order to get everything to fit. The thumb keys with a shared central diamond seemed like a great idea when I was designing it, but in practice it was a pain to use. It was really hard to hit the top key in the diamond. For the keymap I was using at the time, that was the Control key. Emacs-using friends absolutely hated it. I got enough time typing on the Mark 5 that I finally started getting comfortable...except that I found my pinkies just sort of hanging out over the edges of the keyboard much of the time. It took a little while, but at Kaia's urging, I added an extra column for each pinkie on later models. This dramatically improved the usability and comfort for me.

This was right around when my 3D printer finally showed up. I spent most of a month teaching myself the rudiments of 3D modeling with OpenSCAD. It took a lot of tweaking to be able to reliably generate keyboard 'plates' that would reliably seat keyswitches without being so tight they caused the switches to bind or so loose the switches popped out.

Mark 6 Keyboard

The interesting things about the Mark 6 were:

• It was 3D printed. Each of the 'hand' plates took 3-4 hours to print. The bottom shell took about 12.
• The key columns were splayed to better line up with where your fingers end up when you reach
• It was tented -- The middle of the keyboard was just slightly taller than either side.
• It had a rather significant negative slope -- the part of the keyboard under your wrists was higher than the part further away from you.
• The keyplates were separate from the shell of the keyboard. This made it really easy to iterate on key layout separately from keyboard shape.

The things that sucked about the Mark 6 were:

• The column splaying was far too wide. I could reach everything, but it wasn't particularly comfortable.
• The negative slope was far too pronounced. It was just uncomfortable to use with the bottom of the keyboard flat on the desk.
• I still hadn't added the extra columns Kaia had suggested.

Mark 7 Keyboard

The Mark 7 was a fairly straight forward iteration from the Mark 6. Neat things about the Mark 7 included:

• Splitting the thumb and finger keys onto two different plates. This let me slightly change the angle between them.
• Switching from a 5 key arc of thumb keys to a four key arc with a key above the arc and a new 'palm' key. The palm key, in particular, turned out to be pretty amazing. I use it to enable an additional layer of keys. Arrow keys live under HJKL. {}[] live under YUIO, and so on.
• Slightly reducing inter-column finger splaying.
• Finally adding the extra columns of pinky keys. These meant that the ` = ' - keys no longer needed to be hidden away on the second layer.

What didn't work so well in the Mark 7:

• The keyboard shape was still pretty boxy
• The inter-column finger splay was still too wide
• The thumb keys were a bit too far away from the rest of the keyboard.

Mark 8 Keyboard

The Mark 8 was my first attempt to make a thin keyboard. It was identical to the Mark 7, except it was printed as two pieces -- a single key plate and a single bottom shell.

The biggest issues with the Mark 8 were that its shell wasn't structurally sound and that the front edge of the keyboard was sharp and ended up right in the middle of the user's palms.

Mark 9 Keyboard

I spent a full week teaching myself how to design and 3D-print ball joints for the Mark 9. Two of those days were spent figuring out how to print all the parts of a ball joint as a fully assembled unit. Once I had it pretty well worked out, I realized that I was actually better off printing the two halves separately.

Mark 9 Keyboard, in two pieces

Things that were really cool about the Mark 9:

• It had a ball joint!
• You could position the two halves independently!
• It was thin!
• It had rounded corners and edges!
• It was the first keyboard I managed to print in ABS rather than PLA. As such, it just felt a lot nicer. Also, the colors were more exciting. (If pushed, I'll admit that the color choices were dictated by when I ran out of each spool of filament.)
• I slightly reduced the inter-column finger splay. It was starting to feel reasonable.

Things that could have been better about the Mark 9:

• It was basically impossible to use in my lap or tented on a desk -- The balljoint didn't work well enough to use unless the keyboard was on a flat surface.
• The cables I used between the two halves were too brittle and unwieldy.
• It suffered from the same problem as every other 3D-printed keyboard I'd made to date - When I showed it to someone, they got really excited about the fact that I had a 3D printer. In contrast, whenever I showed someone one of the layered acrylic prototype keyboards I'd built, they got excited about the keyboard.

Mark 10 Keyboard

The Mark 10. I don't have a lot to say about the Mark 10.

Things that sucked about the Mark 10:

• While trying to print it, my 3D printer caught on fire.

Things that were great about the Mark 10:

• I was forced to switch back to layering sheets of lasercut acrylic. While frustrating at the time, it was ultimately really, really good.

Mark 11 Keyboard

I built the Mark 11 to take to XOXO. I'd had a lot of time to think and play since I'd made the Mark 9. And the Mark 9 just wasn't a usable keyboard for me. I procrastinated just a little bit too much and didn't have enough time to lasercut it myself. I ended up paying the nice folks at Danger Awesome a rush fee to get it cut within 24 hours after I emailed them my EPS files. Like the earlier lasercut keyboards, it was made out of stacked layers of acrylic. I went back to the completely-clear acrylic I'd used in the Mark 3, except this time I made the topmost plate thicker to better protect the key edges as I slid it in and out of my bag and to slightly raise the typist's hands into a more neutral position. The heart shape didn't work well with the palm keys -- playing around a little bit, I cut out a medium arc around the palm keys. It looked a little bit like a butterfly.

In general, I really liked the Mark 11. It was the design in a while that I was actually able to use as my primary keyboard. People I showed it to also liked it. This made me pretty happy. The comment that most blew me away was "If you made a commercial keyboard just like this, you could sell it in the MoMA Shop."

There were a few things about the Mark 11 that didn't work:

• It was really heavy. Really, really heavy. It turns out that a 9"x13" sheet of 1/2" thick acrylic is heavy. Who knew?
• The sheet of acrylic that served as the keyplate started cracking pretty quickly. I'd seen that a little bit on earlier designs, but for whatever reason, the the Mark 11 was doing a pretty good imitation of a spiderweb.
• The top layer of acrylic (the one in the butterfly shape) did a really good job of putting not one, but two sharp edges under each palm. On top of that, the positions I'd chosen for the screws that held the keyboard together put screws in a perfect place to bite into your palms.

Mark 12 Keyboard

In an effort to cut down size and weight, the Mark 12 changed up the design just a little bit. I made the butterfly shape, now quite intentional, the outer edge of the keyboard. I did my best to keep the footprint the same size as an 11" MacBook Air. To help cut down on weight, I made the bottom layer of the keyboard a bit thinner. To better support the keyplate layer (and cut down on cracking), I made the electronics-wiring layer of the keyboard a full sheet with specific cutouts, rather than a wide outline. To further cut down on cracking, I changed most of the right angle cuts on the keyplate to gently rounded corners. (They may be somewhat out of vogue for web design, but rounded corners are really useful for lasercutting.) I moved the screws so they wouldn't bite into a typist's palms. To give it just a little bit more personality (and to make interlayer dust slightly less obvious, I cut the electronics-wiring layer out of translucent orange acrylic. After assembled, I softened the sharp edge under the typist's palms with a hand file. The layout didn't change much from the Mark 11. Just about the only thing I did was to tighten the inter-column finger splay just a bit more. Based on a study at Berkeley that claims any key spacing of 17mm or more doesn't increase error rate or typing pain for large-handed users, I tightened the baseline inter-key spacing to exactly 18mm. (I'd have tried 17mm, but knew that my current keycaps were just too big.)

The Mark 12 was good. Really good. I liked it. It felt nice to type on. It was fairly compact. It was totally manufacturable. The only real issues I had with it were that the palmrests were about half an inch too small for my hands and I'd misguessed on the lower bound of key spacing I could get away with -- they would sometimes scrape against each other as I pressed them.

Mark 13 Keyboard

I'm typing this on the Mark 13 keyboard. I feel more comfortable on it than on any other keyboard at this point. While I'd like the Keyboard.io Model 01 to have 17mm or 18mm key spacing, I bumped the spacing on the Mark 13 up to 18.5mm to improve the typing experience with the commodity keycaps I have access to. The Mark 13 also improved the palm rest shape and played around a little bit with the butterfly shape to make it slightly prettier. The biggest change in the Mark 13 is inside. I'm still using the same solder and wire-wrap technique I've been using for most of the past year, but the Mark 13 is the first keyboard powered by an Arduino Micro rather than a Teensy.

The Teensy is a fantastic prototyping platform. And there are several very, very nice opensource keyboard drivers available for it. As I've been starting to look at my options for putting the keyboard into production, I've been trying to figure out what I want to use for a microcontroller. The Teensy is based on the Atmel ATMega32u4. It's a neat little single-chip solution that has enough pins to drive a keyboard and a few other peripherals and has native support for acting as a USB device. Unfortunately, the Teensy's bootloader is proprietary. That means that if I wanted to ship a "Teensy-compatible" keyboard, I'd need to either actually put a Teensy inside the keyboard or license the Teensy bootloader. Neither of those felt right.

The Arduino Micro has very similar capabilities to the Teensy. It's based on the same ATMega32u4 microcontroller. It has a comparable (thought slightly reduced) pin count. It costs about the same amount of money. The differences are in the development environment, the bootloader and in the license. As an Arduino, it's programmable directly in the vanilla Arduino IDE. It even includes native support for 'emulating' a USB keyboard and mouse. The bootloader is an AVR109 compatible Arduino bootloader. It's free to use and modify. The hardware design is also free to use and modify. So, while an Arduino Micro is around $25, putting all the parts of a Micro on our PCB will cost considerably less. And it'll be programmable with the Arduino IDE.

There was one teensy little problem. (Sorry, couldn't resist.) Nobody had, as far as I could tell, ever released a full keyboard driver for Arduino. But Arduino C was, I was told, really easy to pick up. I hadn't actually written any C in well over 15 years and the closest to embedded development I'd ever gotten was writing Java for Android. But hey, how hard could it be?

I wrote the first fully functioning version of KeyboardioFirmware in an hour and a half. While watching a movie. While tipsy. It turns out that Arduino really is easy to develop for. Since then, I've added support for keyboard-driven mouse emulation, multiple keymaps, rudimentary macros and dramatically improved reliability and memory efficiency.

The big issues I have with the Mark 13 are that it's heavy and that acrylic scratches and cracks easily. It also traps dust between layers and shows fingerprints and smudges like you wouldn't believe.

So, you ask, if the Mark 13 is basically the keyboard I want to ship, what's next?

Well, none of the techniques and technologies I've been using to prototype are going to work for a production run.

I've been talking to a few potential production partners in Taiwan and China, but folks are being slow to engage.

It's time to learn about D4M. (Design for Manufacturing)

The first and most obvious issue to solve is the circuit board. To date, every single keyboard I've built has been hand wired key by key and diode by diode. My friends who are electrical engineers recoil in horror when I tell them that. "But Jesse, it's so much easier to just design and fab a PCB," they say. Truth be told, circuit board design terrified me. I had absolutely no idea where to start.

Most of the Maker movement seems to have standardized on CadSoft EAGLE. It's relatively user friendly. And I mean relatively. It's awful, obtuse and incredibly dated. But compared to other CAD packages, it's astonishingly clean and intuitive. It's free to use if you're building open hardware and your board size is below a few inches square. A commercial license of EAGLE that lifts these restrictions is a few thousand dollars. That wasn't really going to work for me.

Over the past year, I've tried to design a keyboard PCB every few months. It was never really all that pressing and I'd invariably give up in frustration after banging my head against the CAD software for a while. I tried gEDA, KiCAD, circuits.io, and a host of other packages that don't spring readily to mind. After some encouragement at a conference in early november, I gave circuits.io another shot. It worked great, up to a point. By the time I'd built a grid of about 20 keys, their webui was so slow that Chrome would throw the "Kill the naughty page?" dialog after every operation. But I'd designed enough of a circuit that I thought I might understand what to do next.

I decided to give Upverter a shot next. It was slightly less polished and friendly than circuits.io, but it coped just fine with the schematic for the entire keyboard. I even managed to get a basic PCB laid out. The problem came in when I was trying to move and angle the keys. Each change took some manual calculation and a relatively large number of clicks. It just wasn't quite done enough for this project. That said, Upverter was actually pretty nice to use. And when I tried to use their 'live chat' feature to ask some how-to questions about the product late on a Friday night, one of the developers walked me through my issues and helped me find workarounds for features they didn't have yet. This was for a user with a free account. I've since upgraded to a paid account. If Upverter can handle what you're doing, it's a great choice for circuit design.

From there, I decided it was time to give KiCAD another shot. Previous attempts at KiCAD failed for a variety of reasons:

• I had no idea what I was trying to do
• I was trying to use KiCAD in a Linux VM on a Mac, without an external 3 button mouse
• I had no idea what I was trying to do

This time things were different:

• I had the vaguest idea of what I was trying to do
• I was trying to use KiCAD in a Linux VM on a Mac, with an external 3 button mouse

Starting with the matrix I'd designed in Upverter and the component definitions from KiCAD-Keyboard-Tutorial, I managed to piece together a keyboard schematic and PCB design. KiCAD's rotation and placement UI isn't a whole lot better than Upverter's, but it's better enough that I managed to actually get a board designed. All in all, it took me about 4 days. Much of that was tweaking and learning. When I tried redesigning the board from scratch, I had it done in about 4 hours. Lest you think "Ok, he now has a production PCB design. Where's my damn keyboard?" I should admit that the PCBs I've designed to date have a slot for a commercially produced Arduino Micro. The production PCB will need to have an Arduino Micro (including a few surface-mounted components) cloned onto it. I either need to further level up in circuit design or enlist some professional help.

Once I had what I thought was a reasonable board design, I exported Gerber and Drill files and started shopping them around to PCB prototyping houses. Most of these companies gave me a "quick quote" after I gave them a little bit of metadata and uploaded my Gerbers and drill files. With the exception of Seeed Studio, everybody had a process that involved me interacting with a sales person before my boards got made. Quotes I got back were all over the map. I think the most expensive I got back was a cost of $270 for a single prototype board and 50 for each additional copy. Most were on the order of $100 for the first board and $25 for each additional board with prices falling off the more I ordered. Turnaround times quoted to me ranged from "We can FedEx overnight the boards to you tomorrow, if you're willing to give us your firstborn child" to "How about we think about making them in two weeks and then put them on a boat?"

Pretty much everybody had an intro/prototyping offer that would have been a lot cheaper. And pretty much everybody said I wasn't eligible for it because my boards were way, way too big.

Golden Phoenix were the most responsive vendor and their sales person actually flagged a technical issue with the Gerber files I'd submitted to them. They weren't the most cost effective vendor for the quantity of boards I was ordering. That honor went to Seeed Studio's "Propagate" offering.

Seeed Studio's minimum order is 5 boards. As I ran the numbers, it turned out that getting 10 boards would be only a few dollars more than getting 5. So, for $150 in product cost and $50 in FedEx shipping, I have 10 prototype boards that are currently "In Production" and should soon be "Shipped". I have no illusions about having my first board design actually work, but I'm hopeful.

Once we have our PCB sorted out and our design finalized, we intend to do the whole Kickstarter thing. If you want to know when we're ready to take your money, head on over to http://keyboard.io and sign up for our announcement list.

Shanghai, late 2013. Day One. (The Electronic Component Market)

This was my third trip to Shanghai. The first one was in 1993. The second was in 2010. Things had changed less between the two most recent trips than between the first two trips. That's hardly surprising.

The first time I flew into Shanghai, My dad and I flew into Hongiao Airport, took a taxi to the decaying Peace Hotel on the Bund and crashed out for 12 hours. Across the river was the Oriental Pearl TV Tower ...and not much else.

When we woke up, we started making our way through the legions of blue-grey-suited pedestrians and cyclists thronging Nanjing Road.

We found ourselves in front of a crowded little dumpling place on a side street. After observing for a bit, we figured out the system: hand over some cash and get issued plastic tokens. Push your way through the crowd to the kitchen counter and hand over your tokens in exchange for delicious looking fried dumplings. We were starving. So we pantomimed that we wanted six dumplings. (Counting on your fingers in Chinese is different than in English. You can get to 10 on one hand.) We got our six tokens. They were an impossibly cheap 20 cents or so. We pushed our way up to the counter and handed them over. The cook started shoveling little greasy fried balls of pork and deliciousness into a paper bag. He didn't stop at 6. He didn't stop at 7. He didn't stop at 8. Eventually we figured out that we'd bought six orders of four dumplings. Despite our best efforts, we only got through about 20 of them before sharing our bounty with a homeless guy in a park.

I remember wandering through dusty, sleepy department stores on Nanjing Road. I found the electronics counter tucked away on the 2nd or 3rd floor. A small box caught my eye. It looked a little like the Gameboy I'd left at home. I was delighted to discover that it was an unlicensed implementation of Tetris that I could almost fit in my pocket.

From Shanghai, we set out across what felt like a very broad swath of Eastern China by hard-seat train. My only memory of Shanghai's main train station is one of low ceilings, signs showing that explosives and fireworks were prohibited on trains and big X-Ray machines for EVERY piece of luggage. The security staff gestured that we didn't need to scan our bags and just waved us through.

The second time I was in Shanghai was Christmas 2010. Kaia and I flew into the giant super-modern PuDong airport. From there, we paid a pittance to take the Maglev train into downtown PuDong - the mega-city that the Chinese government built by fiat in what had basically been rice paddies on my first trip to Shanghai.

We stayed at what was nominally a new-construction Sheraton in Pudong. They upgraded us to a two-room suite on a high floor with a glorious view of the bridges spanning the river and the Bund.

At one point, I went looking for 'interesting' electronics. The recommendation I got put me at what I can only describe as an electronics fake market. I was looking for an interesting Android tablet or something. When I asked about Android phones, I was handed an 'Android iPhone! Dual-SIM!' - It looked sort of like an iPhone. The OS it was running was a dumbphone OS upgraded with ripped icons from iOS and support for a resistive touchscreen. The only Android 2.x tablet I was shown...did not boot. Nor did any of the 4 others they took out of plastic wrap to try to demo. Eventually, the salesperson apologized and said she couldn't show me a working one. In general, though, there was relatively wide availability of high-end tech. When we visited the Super Brand Mall, Best Buy had the relatively complete, if uninspiring selection of gear you'd expect to find at a Best Buy. An underground Apple Store (that wouldn't look out of place in New York or San Francisco) was situated in the next mall over. Across the street from the two malls was the Oriental Pearl TV Tower. Underneath the tower was a sort of awesome but incredibly kitschy museum of the history of Shanghai.

Locals were fairly brand-conscious. Sure, I was offered a fake Rolex, but the tout offering it had stationed himself in front of the Rolex shop on Nanjing Road, a few blocks from American Apparel's China flagship store.

The phrase I use to sum up my impressions of late 2010 Shanghai is 'Starbucks across the street from another Starbucks.'

But this was supposed to be my 2013 Shanghai travelogue.

The view from the airport lounge where I scrambled to install Chrubuntu on my Chromebook.

I'm going to skip over the gory details of my IT setup for this trip -- that's a subject for another post. The very short version is that I arrived with a Google-flavored HTC One with my regular T-Mobile SIM and an ARM Chromebook running Chrubuntu. On my phone, I had access to Twitter and Foursquare. Both devices were signed into a throwaway Google account.

I arrived, somewhat bedraggled, at PuDong airport. I turned on my phone and was greeted by an SMS telling me that international data roaming in China would be rate-limited to EDGE speeds but would be free. Yay T-Mobile!

The next thing my phone told me was that in the 14 hours I'd been offline on my way to china, updates for a dozen or so Google apps had been uploaded to the Play Store. It was almost certainly a coincidence.

I decided that given how tired I was, I could treat myself to a taxi. I spent a few minutes stumbling around the arrivals hall of the airport looking for an ATM. A liveried driver hanging out at an official looking 'Ground Transfers' desk tried to convince me that she'd offer me a much better rate to the hotel than the hotel's airport transfer service. She quoted a number approximately 3x what a cab was supposed to cost. When I told her what a cab cost, she looked a little disappointed, said 'taxis are downstairs' and wandered off.

Dear San Franciscans - the Shanghainese have developed artificial fog technology and may soon put @carlthefog out of business

Stepping out of the airport, I walked into a wall of air. At least it felt that way. It was insanely smoggy. I didn't find out until later that it had been 'keep the kids and grandparents inside, halt construction projects and ban fireworks' smoggy. The cab ride was uneventful. I'd printed a copy of the Chinese-language driving directions from the airport to my hotel during my downtime at the airport in Chicago.

Some of the drive from PuDong to Shanghai felt like driving through a megalopolis. Some of it felt like driving through a post-apocalyptic wasteland.

I spent the trip splitting my attention between marveling at the endless tracts of buildings across PuDong, Friday afternoon traffic and an email conversation with Thomas Yao,the leader of the Shanghai Linux Users' Group. I was pretty shattered, but Thomas talked me into going out for dinner with him later in the evening.

The cab pulled up at the Sheraton Hongkou, which I'd picked because it had an astonishing promo rate and was located across the street from a subway station on the Shanghai side of the river. What I hadn't realized at the time was that it was a brand new skyscraper in an area that was otherwise completely un-redeveloped.

The Sheraton was...well, it was a very, very nice Sheraton. From the bedroom-sized shower with a claw-foot tub and a view of downtown Shanghai to the heated marble floor by the sink and the french press for coffee and the $10 bottle of Evian, it was what you'd expect.

Heading out for dinner with Thomas, I asked the front desk if the RFID transit card I had in my wallet was a Shanghai subway pass. He told me he thought it was, but wasn't sure. It didn't work, so I bought a 40 cent subway ticket to Thomas' office on the Pudong side of the river.

Coming out of the subway, there was a small flea-market, consisting of sweaters, nuts, roasted snacks and iPhone cases. So many iPhone cases.

I walked into the GitCafe office to find Thomas and one of his coworkers playing XBox soccer on a giant wallscreen. They finished up their game, we chatted a bit and Thomas and I headed off for dinner. I asked him about the RFID card the clerk thought might be a Shanghai subway card. Thomas pointed out the large text that said '北京' (Beijing) before helping me buy an actual Shanghai subway pass.

The old TV tower got a new lease on life as the host of the hourly laser show.

We had dinner at 代官山, one of Thomas' favorite restaurants at Super Brand Mall. Very few parts of dinner were things I recognized, but everything was tasty. One of the oddest bits was the drinks, which were some sort of Coca-Cola and citrus concoction with tiny little citrus fruits served in glass bottles heavy enough to kill someone. As we were leaving the mall, the Oriental Pearl TV Tower lit up with a laser light show. Green laserbeams started hitting nearby buildings and giant laser-projected horses stampeded across the tower's base.

Some of the local cafe chains have made fascinating branding choices.

We made plans to meet up Wednesday evening at XinCheJian, the local hackerspace. From there, I headed home and passed out until morning.

Consumerism!

Saturday, I set off to find the Beijing Street electronic components market Thomas had recommended to me. It was fairly near Nanjing Road, so I hopped on the subway and popped up in front of the Sony Store and a gigantic Forever 21. Across the street was the first block of the Nanjing Road pedestrian mall. As soon as I set foot on the pedestrian mall, the touts hit. "Hey Mister. You want a watch?" "No." "You want a handbag?" "No." "Massage?" "No." "Lady massage? Very sexy girls." "No." And it didn't let up. From there on in, if I was on Nanjing Road, a tout was trying to sell me a Rolex, a designer handbag or a happy-ending massage. Some of the touts were men. Some were women. All were reasonably young. Some were more aggressive about it than others. Some only got in a single question as I walked past. Others followed me for half a block. That's the last I'll mention of the touts.

Just like home!

I walked down Nanjing Road for a couple blocks -- past a mobbed Apple Store, a gourmet grocery store, Gucci and a bunch of other high-end western shops. Guided by Google Maps, I took a right toward Beijing Road. Things quickly became more chaotic. Sidewalks and traffic lights became more...advisory than anything else. The side street was lined with small local shops, restaurants and...sort of ramshackle holes where there should be more shops.

Seconds before, this shop window had been shilling for DeWalt

As I hit Beijing Street, things changed again. Apparently that section of Beijing Street is known as 'Hardware street.' On the corner as I walked up was a sort of micromall of power tools, hand tools and gas generators. Some of the stuff there was from Chinese brands I'd never heard of like Dongcheng, but there was just as much stuff (and advertising) from DeWalt, Craftsman and Milwaukee.

Plumbing supplies on Beijing Street

Perhaps I could interest you in some industrial springs in a range of festive colors?

Walking down Beijing Street, there were whole stretches of shops that sold nothing but magnets or bearings, tubing, connectors or brushes. Across the street, I found the 7 story "Technology Jingcheng Electron Market".

Every kiosk also sold a range of diodes, capacitors, oscillators and so on, but they weren't nearly as photogenic.

See. Told you so.

I started by wandering in the front door. A few dozen kiosks filled almost all available floor space. The kiosks had demos of the various LEDs they had for sale. They also appeared to sell everything else. Under glass various kiosks had piles of different sorts of switches, diodes, ICs, power adaptors, LCDs and a variety of other parts.

Some of the kiosks were filled with unstable stacks of partial reels of surface-mount components.

And kids. Kids everwhere. It was Saturday, so everyone just brought their babies, toddlers and 10 year-olds to hang out.

Every kiosk had one display case on wheels that served as a door..of sorts.

Heading downstairs into the basement, I found more of the same, but also a little more work being done. A few shopkeepers had customers laptops open and were attacking their motherboards with soldering irons. Things in the basement were generally a bit better organized than on the first floor.

If you need custom faceplates for your milking machines, this is the place to go.

The second floor was...probably about 50% bigger than the first floor and connected to the next building over. As I was doing the tour of shops that sold nothing but spools of surface-mount microcontrollers (and there were probably about 20 of them), women with small sheafs of paper listing the parts their clients needed would dart in an out of various shops placing or picking up orders.

At some point, a guy on a powered self-balancing unicycle zoomed past me.

I wouldn't realize it was odd until days later, but not a single person on any of the 5 occupied floors of the component market said a single word to me without me trying to start a conversation first. And I only did that twice.

I seriously considered trying to bring one of these soldering station microscopes home in my suitcase.

I make keyboards. I hadn't really thought about buying keyboard parts on this trip. Had I planned ahead, I could have gotten someone at the electronics market to design me a PCB for my next model. As I was walking around, I kept an eye on the keyswitches that were being offered for sale, on the off chance that someone had a good deal on the switches I use (or interesting alternatives). Somewhere on the third floor, I finally found someone selling Cherry keyswitches. The vendor didn't speak any English (and, to a first approximation, I speak no Chinese.) Using Google Translate, I explained that I wanted to know how much 200 of those keyswitches would cost. One of the two folks behind the counter picks up the switch I wanted and ran off. About 10 minutes later, he turned up again and wrote down a price...which was easily twice what they should cost. I wrote down what I wanted to pay. He shook his head, made an X with his arms and turned away from me. As I walked away, he was taking cameraphone pictures of the keyswitch.

Very, very few of the vendors had posted price lists like this one.

There were three of these shops in a row

The higher floors of the central market held more and more 'finished' goods. The shops in the secondary building tended to sell only a single sort of thing. There were bubblewrap shops. There were X86 CPU shops. There were packaging shops. There were shops that only made faceplates. There were cabling shops. You get the idea.

I got all the way to the top of the market without finding another vendor selling keyswitches. There had to be one -- the merchant with the high price really clearly hadn't left the building when he'd run off to get me a price. But it was lunch time and I was a little burned out on electronic components.

If I'd been planning ahead, I probably could have gotten some keyboard PCBs made while I waited.

As I was walking across the second or third floor to get to the escalator, I noticed a tiny, tiny little kiosk (maybe 3 feet square) that had some keycaps on their "what we sell" board. Looking closer, they had an awful photocopy of the data sheet for Cherry keyswitches taped to the front of their display case. Getting into a conversation with the seller, it turned out that she had a pretty reasonable selection of Cherry keyswitches and keycaps. Her pricing for keyswitches was among the best I've found anywhere, though I know she was still making a decent profit. Her pricing on keycaps was astonishingly good for what she was selling. So I can find it later, her email is [email protected] and her phone is 021-53083556. The website on her business card doesn't exist. I walked out about $60 poorer, but 200 Cherry keyswitches and about 700 keycaps richer.

Over the course of the morning, I became a big fan of the Beijing-lu Electronic components market.

It was time for lunch.

Airplane Mode for Glass

I've built my first little piece of software for Google Glass.

I flew home from SF yesterday and realized that there was no way (short of installing a very crashy Settings.apk) to enable Airplane Mode on my Glass.

That seemed like a reasonable enough "small" starter project.

This is really, really only for folks who are already comfortable running third party apps on their Glass. If you don't know how to sideload apps with adb, please don't install this.

You can grab the initial build at:

https://www.dropbox.com/s/rtbt7vc3bz67j3c/GlassAirplane-0.1.apk

Source lives at https://github.com/obra/GlassAirplane

Patches welcome!

Recon MOD Live - a hackable $300 Android wearable (sort of)

I got a MOD Live HUD from Recon Instruments today.
It is, indeed, running Gingerbread.

As it turns out, if you can get it to install an update.zip, it won't check the signatures. Which means it's pretty easy to root :)

Cracking it open, the display is a Kopin, though I don't yet know which model.

It's designed as a look-around display. The prism has a mirrored backing and is wrapped in black plastic. The mirror coating on the prism comes off quite easily with a bit of rubbing alcohol.

So yeah, rootable Android (2.3) wearable computer. $300.

More details as the story develops.

Google I/O 2013 & Google Glass

[crossposted from Google+]

[tl;dr $300 Android wearable computer with a HUD. Has been shipping for quite some time]

Growing up and hanging out near Cambridge, MA, I was always fascinated by the "mediaborgs" - the folks around the Media Lab who were building and using wearable computers. I spent a lot of time trying to figure out how I could get myself a rig. At the time, the $1000+ for a heads-up display was more than I could pull off. I played around with sticking the tiniest laptop I could find (and even a bit of PC104 kit) in a bag and using a Twiddler and Emacs with T.V. Raman 's  emacspeak to have a walking-around computing environment with an audio interface. It was pretty neat, but incredibly clunky. I never really got the hang of it.

Over the years, I made a bunch of half-hearted attempts to get my hands on head mounted display that was functional enough to use and small enough to actually wear. I'd occasionally look around to see if anyone was selling something that seemed workable. Occasionally, I'd poke at http://tekgear.com/hmd.html to see if there was anything that looked reasonable. Generally, though, the cheap options cost around $1000 and are really intended for immersive video or gaming experiences. (Or they're upwards of $10,000 and intended for defense and industrial applications.)

Needless to say, Google Glass somewhat piqued my interest. Google aren't yet making Glass available to folks like me who played the #ifihadglass game. It sounds like they're just getting a handle on the initial production run for folks who were at Google I/O last year.

I got to try Glass pretty early in the conference. The friend demoing it for me was pretty happy with his, but the functionality he was able to show me was...very basic. To a first approximation, all you can do with the current "Mirror" API is to push snippets of text or HTML+CSS to be displayed in the upper-right corner of the wearer's vision.

At one of the early Glass talks at I/O, the speaker mentioned that a "GDK" to allow native development was coming soon. Glass is, indeed, Android under the hood. (4.0.x for now) Suddenly, this was looking a little more interesting.

A couple weeks ago, +Jay Freeman (@saurik) made news by finding an exploit that allowed him to gain root on his Glass. Since then, there's been a bit of a of a hacker scene growing up around Glass. At dinner on Thursday, I  saw a demo of a patched version of Glass Home running on an Android phone. I've heard reports of a homebrew Glass lock-screen app with an improved guest mode, too.

The one session at I/O that I was not going to miss was +Hyunyoung Song  & +P.Y. Laligand  talk on "Voiding your warranty: Hacking glass" ( Linked below, since I can't figure out how to inline it in G+.) Having been shut out of a few over-full sessions earlier in the conference, I went and sat second-row center at the previous session in the same room -- and learned a bunch of useful stuff about what's coming in Google Analytics. (During the GA session, I was seated next to a guy who looked to be trying to get his new Chromebook Pixel into developer mode. I...tried to be helpful. I was a little bit embarrassed to realize that  he was none other than +Liam McLoughlin  (@hexxeh), who, uh, knows a little bit about ChromeOS.

Getting there early was a good call. The session was packed.  Really packed.

H.Y. and P.Y. demoed how to use adb to push a launcher app and a settings app to your Glass and how to pair a Bluetooth HID device (which just works) and talked a little bit about what one can do by treating Glass as just a "regular" Android device. Porting +K-9 Mail  looks incredibly plausible. I'm really glad we never gave up on QVGA support.

Then they got into the good stuff. How to unlock and root your Glass. It's.. really easy. And exactly how you'd assume you'd do it.
https://plus.google.com/118132270929426815661/posts/4MyjGZhN575 is cameraphone shot of the slide from their deck.

To explain just how far one could go, H.Y and P.Y. demoed that one could use one of the Linux Installers on the Play Store to install an Ubuntu chroot on Glass. They said that they'd gotten the idea for the demo from +Greg Priest-Dorman  who "does his development in Emacs on Glass."

The world of computing is a very small place. I remember corresponding with Greg when he was at Vassar in the late '90s. If I recall correctly, my friend +Dave Barker mentioned to Greg that I had a Twiddler I hadn't fallen in love with. He was hoping to get to try out and I was a flaky Wesleyan undergrad, though I'm pretty sure we met and he showed me his wearable when I finally got up to visit friends at Vassar.

Chatting with a few other Googlers, it sounds like there's a fair contingent of Glass developers who use emacs (and possibly emacspeak) on Glass.

So yeah, after the Hacking Glass session, I..really, really want to get back to wearables stuff. As soon as I can get my hands on a Glass, I will.

I think I've found something to tide me over.

On more than one occasion, Artur Bergman has told me how amazingly amazing his ski goggles with a heads-up display are. They have a bunch of skiing-related sensors. I just sort of assumed that they had some little microcontroller and a custom OLED superimposed on the faceplate.

I was wrong. The folks who make the goggles, http://reconinstruments.com,  were exhibiting at I/O. Their next gen product, "Jet",  is a Glass-esque setup with (not-see-through) HMD, an HD camera, bluetooth, wifi, a gigahertz ARM chip running what they say will be a fully unlocked build of Jellybean capable of running regular Android apps. It's going to ship "later in 2013" for "less than a thousand dollars."

So, that's pretty cool. But I can't have one today. As I talked to them a bit more about their existing product, I found out that it was...not quite what I expected. It's a QVGA (320x240) display that they say looks like a 14" screen 5 feet away. It's powered by...a device running (the slightly dated) Android Gingerbread. (In a previous version of this post, I accidentally said it was running Froyo)

Me: "So, I could buy a set of your ski goggles for $449 and rip them apart and get a wearable computer running Android with a heads up display."

Guy from Recon: "Well, you could.The HUD is designed to be taken out of one set of ski goggles and put in new goggles when you upgrade. But, that's kind of a pain in the neck. It'd be easier and cheaper just to buy the HUD from our webshop as a standalone unit. It's $300."

Me: "..."

Me: "..."

Me: "And this is shipping? I can order it today and you already have them in stock?"

Recon: "Oh yeah, I mean this is the old model. It's been out for a while. We've actually discounted it from $400 to $300. It's running Froyo. The new one is much nicer and will be out later this year."

Me: "Please take my money"

So yeah. $300 wearable Android device. Has been shipping for quite a while. You can buy one today. I ordered mine before blogging about it. I'll report back once I've gotten to play with it.

To answer the obvious question:

Yes, I will be building a version of K-9 Mail for heads up displays.

To answer the other obvious question:

Yes, I'm going to be playing with building a Bluetooth input device or two for Android wearables.

Mark 2 Keyboard

It's been quite a while since I've written about my keyboard hacking project.

Since I wrote up the Mark 1 keyboard, I've made 5 more keyboards. I've learned a bunch about soldering, I've learned how to operate a laser cutter and I've learned a bit about 3D printing. I've also learned a bit about ergonomics and keyboard design.

I'm going to take this chronologically, even though that means I'm going to tell you about stuff that I later discovered was...not so right. So, bear with me through some clunky keyboard prototypes. It gets better. This post documents work from January, 2013.

To recap, the Mark 1 keyboard was based on the shell from the ErgoDox. It was a two-hand split layout, which turns out not to work well when you type with your keyboard in your lap. I had the ErgoDox 3D printed by ShapeWays. It was very expensive. Expensive enough that buying a 3D printer didn't sound like a bad idea. It actually sounded like a vaguely plausible idea. The 3D printer I ordered, an Aluminatus from Trinity Labs was going to take a while to ship, so I started looking around for other options. (They have since started shipping. The production units are more expensive than the beta version I got.)

It turns out that Cambridge, MA is home to danger!awesome, a storefront lasercutter shop. Yeah. It's as awesome as it sounds. It isn't particularly dangerous, though. I'm not complaining.

To get a lasercutter to do its thing. you need to feed it a vector file describing the cuts you want it to make.

To design the Mark 2 keyboard, I used my favorite vector drawing package -- Omingraffle. I drew a bunch of 14mm holes in a pattern that seemed to make sense and sent Danger Awesome an eps file.

Two days later, I dropped by their shop and picked up an 11"x17" sheet of green acrylic with a bunch of 14mm square holes cut out of it. The nice folks at danger!awesome weren't quite sure what I was up to, so they saved all the little 14mm square munchkins they'd cut out of the plate.

I brought the sheet home and started sticking Cherry keyswitches into the holes. I quickly discovered that my acrylic sheet was too thick for the keyswitches to stay in place when I pushed them into the holes. It turns out that Cherry keyswitches have cute little clips designed to fit into 1.5mm thick plates. I quickly hit upon a solution that eventually turned out to have been a really bad idea. I...painted superglue around the edge of each key. This had the intended effect of making the keyswitches stay put. It also had the unintended effect of making the keyswitches somewhat...scratchy feeling.

I soldered up the Mark 2 very similarly to how I did the Mark 1. It...took a lot less time, though. Probably only 10-12 hours. (Since then, I've gotten much faster and more accurate. And have better ways of wiring everything up.)

Rather than use the prototyping wires I used to connect the Teensy in the Mark 1 to the keyboard, I decided to try a ribbon cable. I happened to have a bunch of old IDE cables hanging around, so I chopped one end off a cable and started soldering. All in all, it worked pretty well.

I then had a working keyboard....at least as long as I carefully held it in the air so nothing crushed the key wiring. I needed a case. The right thing to do was probably to have more parts lasercut, but I was impatient.

I hopped on my bike and pedaled down to the neighborhood Michael's to look for something I could use for a case. After a bit of wandering around, I found something that worked reasonably well...A picture frame designed for 11"x17" photographs. That got me enough height to make sure my keys and wiring weren't crushed. I let them keep the glass from the frame & had them cut a matte to the outside dimensions of the frame rather than the inside dimensions. Yeah, my keyboard had a paper back. Not great for a production keyboard, but just fine for a prototype.

Within a couple days, it became clear that the keyboard was..not perfect.

I'd designed the hand layouts with a nice finger staggering. but each laid out..straight in front of me. It was a little bit like a flat Kinesis or Maltron. It was typeable, but not amazing.

The key column layout wasn't right.

The keyboard was big.

The picture frame shell was...heavy.

It was a reasonble prototype, but I could do better.

Next up would be the Mark 3. It wasn't right, either.

Pinkies and your brain.

Your pinkies are not exactly your most...adept fingers. I don't mean to imply that I'd be happy to lose mine, but I'm also not exactly happy that the standard QWERTY keyboard sticks keys like Shift, Return, Delete, Tab and Escape out of the way where you need to stretch your pinkies to whack them. If you're an emacs user and have remapped Caps Lock to Control, things don't exactly get easier for your poor left pinkie.

As I've been starting to research keyboard design, I came across a tidbit about the placement of the Shift keys -- The earliest Remington typewriters (the ones by the guy who devised QWERTY) were strictly uppercase affairs. The competition added lowercase through a simple if somewhat...brute force hack. They added a second keyboard. Remington contrived something else - they welded lowercase type to the same hammers as as the uppercase letters and contrived a mechanism to literally shift the typewriter's platen up so the lowercase type would make an impression rather than the uppercase type.

As you might guess from that sort of a solution, there was an engineer involved. Apparently, an engineer who didn't want to spend time reengineering something they'd already built. So, when they went looking for a place to put their new platen shift keys, guess what they did with em? They bolted them on the side and a little out of the way.

And that, my friends, is why Shift lives where it does.

Another paper I was reading alluded to a study that said that one can not properly touch type on a keyboard with more than 50 keys. Looking down at my macbook air's keyboard...yeah. A few more than 50.

Even a happy hacking has more keys than that:

So I set about trying to figure out a keyboard layout that wouldn't put so much emphasis on your least awesome fingers. I'm working from the ErgoDox keyboard design I wrote about earlier.



Those of you who are big into counting might count just over 75 keys there. But the basic layout of the keyboard is what I currently have to work with.

The layout I'm currently using is pictured below. What I've done is to eliminate all but a single column for each pinkie in favor of an additional "blue shift" layer. So far, I'm finding it fairly comfortable and getting used to it pretty quickly. I'd love comments and questions, though.

(Yes, I'm at 52 keys, not 50)

A pound of Sculpey

I'm starting to play around with what my first fully-homebrew keyboard design might look like.

This is my first pass at the left half of a keyboard:



Building a Keyboard: Part 2

An explanation of what I'm trying to do by writing this up

When I started in on this project, I was a complete electronics newbie. I had no memory of holding a soldering iron. (Though as soon as that rosin core got hot, I recognized the smell. I'm pretty sure I must have soldered as a kid or in a past life or something.) I made...a number of mistakes as I built my first keyboard, but in the end I have a fully working keyboard. I'm attempting to recount, from memory, everything I did. Especially everything I did wrong. If you know what you're doing, you probably laughed or cried a fair bit as you read part 1 of this writeup. If you don't know what you're doing, it's my hope that this writeup shows you just how easy it is to build something that you might otherwise consider out of reach.

Wiring up the left hand side for testing

As I finished off Part 1 yesterday, I'd just managed to get the matrix on the left hand side of the keyboard wired up. From there, I wired up some temporary leads to the rows and columns on the left side. I used adapted breadboard wires from Adafruit. These have the advantage of plugging directly into the pins on the Teensy++ microcontroller. If I was working from a PCB, this wouldn't be necessary, but, since I didn't have a PCB to work from I was doing this freehand.

Once I got the rows and columns connected to the Teensy, I found some bad solder joints. I used the solder sucker to undo my bad joints and redid them.

Weird interference issues

Even once I'd debugged the bad solder joints, I was still seeing...weird behavior. Some areas of the keyboard weren't generating keystrokes. My first assumption was that I just had a few bad solder joints in a row. So I redid them. That didn't really help. Sometimes, it changed the failures a bit, but it didn't actually fix things. "I know what this is! I must have toasted some of the diodes by shorting or melting them during some of my ham-fisted soldering." So I replaced the diodes. Nope.

I unplugged the keyboard from the Teensy and started poking around with the multimeter. I couldn't find anything wrong at all. I went back and tested the "bad" diodes with the multimeter (like I should have done in the first place). They were all fine.

I plugged the left hand back into the Teensy. A different region of the keyboard was now misbehaving. Finally, I realized that certain leads from the matrix to the Teensy were misbehaving when they were plugged in next to each other. What was going on is likely obvious to anyone who understands electricity. My assumption is *mumble* *mumble* interference *mumble* shoddy wiring *mumble*. Rejiggering the wires made the problem go away. Not exactly a shining example of root cause analysis, I know.

At this point, it was time to try to wire the two halves of the keyboard together. I just needed to find a 13 wire cable.

Explanation of my keyboard matrix

13 wires, you ask?

Yes. 13 wires. On my wiring of the ErgoDox shells, I have 5 rows of up to 8 columns.

Normal keyboards are typically wired in something like a 6x18 matrix. Because the ErgoDox is a split layout, it's effectively wired as two separate mini-keyboards. The "real" ErgoDox design sticks an IO Expander on one of the hands' PCB so it can be connected to the other one by an 1/8 inch headphone-style cable. That's slightly more advanced than I'm capable of at this point, so I went for the hacky solution - just back-hauling the entire matrix from the left hand over to the right hand side where the Teensy lives.

There was just one small problem. Finding a 13 wire cable.

Trying to find a 13 conductor cable

An 8 connector cable is no problem. Easy to find. You can even go up a bit from there. But try as I might, I couldn't find a reasonable cable with enough wires for me. Then I hit upon an idea.

HDMI!

Big, thick, heavy HDMI cables. They have lots of pins, right? And lots of conductors inside. A quick check of wikipedia confirmed that there were enough wires inside for me. I briefly looked at adding HDMI ports to each side of the keyboard, but couldn't find female HDMI ports with suitable solderable headers. (They're generally fiddly little surface mount components designed to be placed and soldered by a machine, rather than a 30-something just learning basic soldering technique.)

So I pulled out my wire cutters and *snip*, I had a 13+ connector cable that I could solder to both sides of my keyboard.

In the end, I actually soldered the matrix on the left hand side of the keyboard directly to the formerly-HDMI cable. On the righthand side, I soldered each wire of the cable to a strand of the breadboard patch cable I bought from Adafruit. (The female ends on each strand of the patch cables comfortably seats one pin from the Teensy and means I don't have to mess around much when I realize I've screwed up and need to rewire things.)

I connected both halves of my keyboard to the Teensy and plugged the Teensy into my desktop machine. I hit some keys on the right hand. Everything looked fine. I hit some keys on the left side. And...nothing. Nothing at all.

All wires are not the same

It turns out that HDMI cables are made of twisted pairs of various gauges of wires. That fail for this application in exactly the same way as my own twisted rats' nest of cabling did.

In the end, I took some of the jumper wire I got from Adafruit and just used it as a ribbon cable. I tried chaining it, so I could have a 20" cable rather than an 8" cable, but things started misbehaving.

I threaded the jumper cable from the left hand to the right and got it connected to the Teensy. What I had at this point wasn't ideal, but it did work.

Time to put together the keyboard

It was time for final assembly. That sounded so nice. "final". Ha ha ha. No. At a guess, I ended up taking the keyboard shell apart and putting it back together about 20 times after this point.

So, I grabbed the back halves of the keyboard shell and carefully aligned them on top of the front halves. I grabbed some screws I had lying about and....they didn't fit. The screw heads were just a little bit too big to fit in the screw holes printed into the back shell of the ErgoDox.

In Part 1, I described the SLS (Selective Laser Sintering) process Shapeways used to 3D print my keyboard shell. What I ended up with is just white plastic -- It's fairly easy to customize. In this case, I started my customization by picking up my Leatherman and starting to carve out the edges of the screw holes one at a time. This technique was good enough to get the right hand side of the keyboard fully put together. During my initial final assembly, I managed to over-tighten one of the screws causing the plastic on the bottom side of the case to snap, leaving me down one screw hole. Thankfully, Dox (and/or his co-conspirators) nicely over-provisioned the keyboard shell with screws. Being down one screw isn't a significant hardship.

I flipped the keyboard over and connected it up to my desktop and started testing each of the keys....and found that I had a few new key failures. I unscrewed all the screws I'd just managed to tighten and set to work with the multimeter and soldering iron. Mostly, it seems I managed to stress the solder joints connecting the column wires to the keyswitches. A little bit of work with the solder sucker and soldering iron and I was ready for reassembly. I managed to repeat this process a few times. I'm now...rather better at freehand solder joints than I was when I started this project. None of this would have been an issue with a PCB to mount my keyswitches in.

Now that the right hand was behaving, I was ready to screw the left side together. My screws still didn't fit in the holes I needed to sink them into. The correct solution would have been to wait until the next morning and walk down to the hardware store and buy properly sized screws. As you can tell from what I've already written, I haven't exactly done everything...correctly.

Rather than whittle out the screw holes on the left side, I hit upon a technique that seemed to work for me, but is probably quite dangerous and prone to catastrophe. Kids, don't try this at home until and unless an expert weighs in and says I'm just being overly dramatic.

The shell of my keyboard is made from plastic. Sure, it's not injection-molded like most plastic you'll find in a commercial product, but it has most of the properties of regular plastic. I already described how it snaps when it's subjected to too much stress. It also melts when it gets hot. Perhaps you see where I'm going?

I carefully aligned the back shell of the left hand on top of the front shell. I picked up one of my slightly-too-big screws. I placed the screw in the hole I wanted to secure. It did not seat itself properly because the screw head had a larger diameter than the hole I intended it to fill. I turned the temperature of my soldering iron way up. (As I said in the previous paragraph: Kids, don't try this at home.) I rested the tip of the soldering iron on the screw I hoped to sink. I applied a small amount of pressure with the soldering iron. As it became warm, the screw began to sink into the plastic. As it became warm, the plastic began to emit a noxious odor. When the screw appeared to be properly seated, I removed the soldering iron. This seemed to work quite well and I used the same technique for the remainder of the screws.

I can't press the reset button

I think I mentioned earlier that the way one uploads new firmware to the Teensy is by tapping a little black reset button.

That button drops the Teensy into upload mode so you can blow new firmware into its tiny little brain. When you're using a Teensy on a breadboard, this is nice and easy. You can use a finger or a small screwdriver or a tweezer or just about anything to tap that little black button. When it's sealed away inside your keyboard, it's a little bit harder to press. I really, really, really didn't want to have to disassemble my keyboard every time I wanted to reprogram it. So I took advantage of one of the properties of plastic I've already written about. I did something that would probably get me kicked out of electronics class, especially if it's not done in a well ventilated area.

One should never plunge one's soldering iron into plastic. One should never then hold one's soldering iron inside a piece of plastic and slowly melt out a groove of plastic. When one is finished doing things one should never do, one should carefully clean one's soldering iron while it's still hot.

That completed, I could now easily tap the Teensy's reset button with the keyboard fully assembled.

Time to switch to the production firmware!

I carefully tapped each key on my keyboard. Finally, every key registered. Each key only registered once. I was ready to switch the Humble Hacker firmware from "matrix discovery mode" to keyboard mode. That way, rather than each key telling me its coordinates in the matrix, it would instead, you know, generate a keystroke. I'm told this is a desirable property in a keyboard.

Keys aren't registering. WTF?

I realize I should step back a bit and describe the firmware build environment, at least a little bit.

Getting the keyboard firmware built was fairly straightforward, though it did involve a bit of cobbling things together. The Humble Hacker firmware seemed to be the most flexible option for "new keyboard, new matrix" (as opposed to "upgrade an old keyboard"), though there were a number of other options available. At some point, the author broke apart a single "keyboard" repository into a set of repositories - "firmware", "hardware", "remapper" and "kspec". I actually had the most luck following the instructions from the "keyboard" repository which is marked as "DEAD".

In addition to the Humble Hacker source, I needed to install the Teensy Loader in order to blow firmware into the Teensy.

To build that firmware, I needed a crosscompiler toolchain. The last time I needed a cross-compiler toolchain, I had to commit unspeakable acts involving multiple bootstrapping builds of gcc, insane sets of shell scripts and a summoning grid. It was bad enough that I ended up just installing a compiler on a Nokia N800 and building things there.

Thankfully, things are easier these days.

I downloaded an installable cross-compiler toolchain. It took about 10 minutes. No lurking horrors needed to be placated with the offering of a child-to-be-born. No contracts in blood. No bootstrap compiler. Not even a shell script.

I recall a little bit of futzing around to try to get the kspec tool to build from the Humble Hacker repository. In the end I just used a prebuilt version.

So, back to the keyboard build-out.

I turned off the "matrix discovery mode" in the humble hacker firmware. I did the bare minimum I needed to get the "Q" key to print a "Q" on screen. I rebuilt the firmware, tapped the little black button on the Teensy with a screwdriver and flashed the new firmware.

Ready for glory, I tapped "Q" and...nothing.

I reflashed the firmware and tried again. Nothing.

I turned matrix discovery mode back on. Everything was great.

I reflashed the firmware and tried again. Nothing.

UTSL

I opened up the source to the Humble Hacker firmware and started reading code. Apparently, it's more common to wire your diodes on the columns, rather than the rows.

Oops.

At this point, I was pretty good at rewiring the keyboard. I was also pretty sick of rewiring the keyboard. But there was an easier way.

Lie to the firmware

Why yes, Mr. Firmware. My keyboard does have 10 columns and 14 rows. (Astute readers will note that doesn't jibe very well with my claim of an a 5x8 matrix on each hand. It turned out to be a little bit easier to give each hand 5x7 to itself and then to double up on one "row".)

Success.

My "Q" registered just fine.

I filled in more of the kspec matrix.

Keyboard:Doxy

Matrix:
    /*  F4      F3      F7      F5      F6      D4      D3      D2      D1      D0                  */
    /*  0       1       2       3       4       5       6       7       8       9                   */
  Row:  EQUAL   TAB     CAPS    LSHIFT  BLQ     --      --      RALT    PGUP    PGDN      /*  0  C7 */
  Row:  1       Q       A       Z       LBRKT   --      --      --      --      --        /*  1  C3 */
  Row:  2       W       S       X       RBRKT   --      --      --      --      --        /*  2  C4 */
  Row:  3       E       D       C       LFING1  --      --      --      --      --        /*  3  C6 */
  Row:  4       R       F       V       LFING2  --      --      --      --      --        /*  4  C5 */
  Row:  5       T       G       B       BKSP    --      --      --      --      --        /*  5  C1 */
  Row:  HOME    LIDX2   LIDX3   LCTRL   DELETE  --      --      --      --      --        /*  6  C0 */
  Row:  --      --      LORDER  LGRN2   LFUNC   --      --      --      --      --        /*  6  C2 */
  Row:  --      --      --      --      --      RIDX1   RIDX2   RIDX3   RCTRL   ENTER     /*  7  B1 */
  Row:  --      --      --      --      --      6       Y       H       N       SPACE     /*  8  B2 */
  Row:  --      --      --      --      --      7       U       J       M       LARROW    /*  9  B4 */
  Row:  --      --      --      --      --      8       I       K       COMMA   DARROW    /*  10 B3 */
  Row:  --      --      --      --      --      9       O       L       PERIOD  UARROW    /*  11 B5 */
  Row:  --      --      --      --      --      0       P       SEMI    SLASH   RARROW    /*  12 B7 */
  Row:  --      --      --      --      --      MINUS   BSLASH  QUOTE   RSHIFT  INS       /*  13 B0 */

  /*       0   1   2   3   4   5   6   7   8   9   */
  ColPins:PF4 PF3 PF7 PF5 PF6 PD4 PD3 PD2 PD1 PD0

  /*       0   1   2   3   4   5   6   7   8   9   10  11  12  13  14 */
  RowPins:PC7 PC3 PC4 PC6 PC5 PC1 PC0 PC2 PB1 PB2 PB4 PB3 PB5 PB7 PB0

I filled in the matrix-to-keys table. I'll spare you the bulk of that table, but to give you the flavor of things, it looks like this:

  Key:Q Map:q_and_Q                                    tl:"Q"
  Key:W Map:w_and_W                                    tl:"W"
  Key:E Map:e_and_E                                    tl:"E"
  Key:R Map:r_and_R                                    tl:"R"
  Key:T Map:t_and_T                                    tl:"T"
  Key:Y Map:y_and_Y                                    tl:"Y"

The Humble Hacker firmware has support for multiple (toggleable) keyboard layers. You can do just about anything you want. Native Dvorak keyboard? No problem. Native Colemak keyboard? Sure thing. Design your own. You can do that if you want. You can't reprogram the keyboard without installing a firmware update, but there's no reason you couldn't write firmware that could do that.

Keycaps I ordered from WASD

Knowing (hoping) that I would eventually have a keyboard I needed to type on, I had ordered a set of keycaps from WASD Keyboards earlier in the year. I'd ordered, basically, "one keyboard" of keys.

Keycap shapes

I set about placing the right keycaps on the right keys. Just click em in place, right? Not so much. If you look at most modern keyboards (other than laptop or ultra-thin keyboards), you'll see that the keys have a pleasing sculpted shape. Each row has its own shape.

The ErgoDox shape isn't exactly the same as your typical desktop keyboard. Nor does it have all the same keys. It needs a couple weird-shaped vertical keys and a whole slew of slightly-wider-than-normal keys. Once I got a full set of keys on the keyboard, it felt...weird. The shapes just didn't fit.

Now, where have I seen this layout before?

I hadn't payed incredibly close attention to the layout of the ErgoDox - It had some properties I really cared about (like keys aligned in columns and clusters of keys designed to be pressed with your thumbs). Past that, it was just the first thing that looked even vaguely plausible.

Once I actually thought about it, I realized where I'd seen a layout like that before. It was, in fact, glaringly obvious. I just hadn't realized how glaringly obvious it was.

The ErgoDox Keyboard

The Kinesis Contoured Keyboard

It just so happened that I had an old, dead Kinesis lying around. (Everybody does, right?) I harvested its keycaps and started pulling the keys I'd bought from WASD off of the ErgoDox. As I did so, I managed to yank one of the keyswitches up. After a small detour to the soldering station, I was back in business. (While I had the keyboard open, I locked down most of the keys by painting the edges of the keyswitches with superglue.)I was rather more careful as I pulled the remaining keycaps. I'd been using my fingers for the first few.



After the accident, I switched to a key-puller. Yep, there's a specialized tool for pulling keys off a keyboard. A basic key-puller looks like this:



That's what I started with. As I continued, I managed to dislodge another few keys, so I dug out a higher-end key-puller that WASD had sent me free with my keycap order:

Finally, the working keyboard

Thanksgiving

I spent Thanksgiving in northern Virginia with family. I'd brought along my new keyboard. TSA at Logan were....curious about my keyboard. And surprised I don't work at MIT. But totally comfortable with weird hardware with lots of bad solder joints.

Shortly after getting to Virginia, I noticed that my "A" key was frequently generating two "A" characters each time I tapped it. I wasn't 100% sure what was wrong, but based on past experience, I was willing to go with my gut. I would have been willing to bet money that it was a bad solder joint.

My father-in-law was quite accommodating and I soon found myself at the kitchen table warming up his soldering rig.

Five minutes later, I had an A key that generated only a single "A".

All told, It took me nearly 40 hours of work

How do I know how long this took, you ask? I spent a number of years in consulting and am careful to run a timer for everything I do so I can charge appropriately. No, wait. That's not it. I've never been much good at time accounting. I didn't think very hard about how long it was taking me to build my first keyboard. I didn't really want to think very hard about it. I sort of wish I didn't know how long it took. But I do.

Remember how, back in Part 1, I said that as I sat down for my first soldering experiment I started the pilot of Community on Hulu? Well, as I was futzing with the firmware, I ran out of Community to watch. That'd be 71 half-hour episodes. To have _something_ on as I was finishing up, I put on the pilot of Modern Family. I...did not enjoy that and will not be repeating the mistake.

So, do I like it?

Yes. It's not quite my ideal keyboard or keyboard layout and is different enough than everything I've ever spent time typing on that I'm still getting somewhat fatigued using it for more than a short period if time, but I'm getting better.

It's nicely portable. I quite like being able to fold it in half and tuck it away for transport.

I know how it works. A friend commented that this is one keyboard I'd hate to spill something into. Thinking about it, I realized that I'm actually less worried about something bad happening to this keyboard. I'm confident that, given minimal (and fairly ubiquitous) tools I could repair it without too much effort.

Where am I headed next?

I have...ideas for some novel keyboard designs that I'd like to try out. When I'm back from holiday travel, I'm going to start in on an original design. I'm not 100% sure what I'm going to build, but it might be something with a layout like this:
